Wilder測試治具
Capabilities
- TBT/DP (Alt Mode), USB Type-C™ (Native Mode)
- Supports LFPS Pinging for USB compliance test pattern cycling
- Built in DisplayPort Receiver to enable source DUT compliance patterns
- Adjustable AUX amplitude settings for AUX sensitivity testing
- Lane Flip Automation
General Description
Wilder’s Alt-Mode solution allows for adjacent Type-C testing by enabling users to switch into
selected modes and carry out electrical validation without having to change TPA configuration. The
side-by-side design provides a flexible, robust option for DisplayPort™ Certification USB/Thunderbolt™ Pre-Certification.
DUTC Kit: 640-0840-000
DPC TPA Kit: 640-0800-000
USBC TPA Kit: 640-0834-000
