PackerMicro D-Probe 40/20 GHz
Key features:
High Bandwidth : DC to 40 GHz
Low Insertion Loss : < 3 dB @ 40 GHz for probe pitch < 0.5 mm
Ruggedness : Strong enough for direct probing test pads on uneven surfaces
High Repeatability : No moving parts
Applications : Measurements for Delta-L + PCB, DDR memory, PCIe, HDMI, Display Port, and 100 Gigabit Ethernet boards
